Basic Control Si38-304
90 Function
RX(Y)5M
STEP INV
1 52Hz
2 57Hz
3 62Hz
4 68Hz
5 74Hz
6 81Hz
7 88Hz
8 96Hz
9 104Hz
10 110Hz
11 116Hz
12 124Hz
13 133Hz
14 143Hz
15 158Hz
16 165Hz
17 177Hz
18 189Hz
19 202Hz
20 210Hz
RX(Y)8,10,12M
STEP INV STD1
1 52Hz OFF
2 57Hz OFF
3 62Hz OFF
4 68Hz OFF
5 74Hz OFF
6 81Hz OFF
7 88Hz OFF
8 96Hz OFF
9 104Hz OFF
10 110Hz OFF
11 116Hz OFF
12 124Hz OFF
13 133Hz OFF
14 143Hz OFF
15 158Hz OFF
16 165Hz OFF
17 177Hz OFF
18 189Hz OFF
19 202Hz OFF
20 210Hz OFF
21 52Hz ON
22 74Hz ON
23 96Hz ON
24 116Hz ON
25 133Hz ON
26 158Hz ON
27 177Hz ON
28 202Hz ON
29 210Hz ON
RX(Y)14,16M
STEP INV STD1 STD2
1 52Hz OFF OFF
2 57Hz OFF OFF
3 62Hz OFF OFF
4 68Hz OFF OFF
5 74Hz OFF OFF
6 81Hz OFF OFF
7 88Hz OFF OFF
8 96Hz OFF OFF
9 104Hz OFF OFF
10 110Hz OFF OFF
11 116Hz OFF OFF
12 124Hz OFF OFF
13 133Hz OFF OFF
14 143Hz OFF OFF
15 158Hz OFF OFF
16 165Hz OFF OFF
17 177Hz OFF OFF
18 189Hz OFF OFF
19 202Hz OFF OFF
20 210Hz OFF OFF
21 52Hz ON OFF
22 74Hz ON OFF
23 96Hz ON OFF
24 116Hz ON OFF
25 133Hz ON OFF
26 158Hz ON OFF
27 177Hz ON OFF
28 189Hz ON OFF
29 52Hz ON ON
30 88Hz ON ON
31 124Hz ON ON
32 158Hz ON ON
33 189Hz ON ON
RX(Y)18,20,22M
STEP
Master unit
INV
Slave unit
INV
STD unit
No.1
STD unit
No.2
1 52Hz OFF OFF OFF
2 57Hz OFF OFF OFF
3 62Hz OFF OFF OFF
4 68Hz OFF OFF OFF
5 74Hz OFF OFF OFF
6 81Hz OFF OFF OFF
7 88Hz OFF OFF OFF
8 96Hz OFF OFF OFF
9 104Hz OFF OFF OFF
10 110Hz OFF OFF OFF
11 116Hz OFF OFF OFF
12 124Hz OFF OFF OFF
13 133Hz OFF OFF OFF
14 143Hz OFF OFF OFF
15 158Hz OFF OFF OFF
16 165Hz OFF OFF OFF
17 177Hz OFF OFF OFF
18 189Hz OFF OFF OFF
19 202Hz OFF OFF OFF
20 210Hz OFF OFF OFF
21 52Hz 189Hz OFF OFF
22 74Hz 189Hz OFF OFF
23 96Hz 189Hz OFF OFF
24 116Hz 189Hz OFF OFF
25 133Hz 189Hz OFF OFF
26 158Hz 189Hz OFF OFF
27 177Hz 189Hz OFF OFF
28 202Hz 189Hz OFF OFF
29 210Hz 189Hz OFF OFF
30 52Hz 189Hz ON OFF
31 88Hz 189Hz ON OFF
32 124Hz 189Hz ON OFF
33 158Hz 189Hz ON OFF
34 189Hz 189Hz ON OFF
35 210Hz 189Hz ON OFF
36 52Hz 189Hz ON ON
37 88Hz 189Hz ON ON
38 124Hz 189Hz ON ON
39 158Hz 189Hz ON ON
40 189Hz 189Hz ON ON
41 210Hz 189Hz ON ON
RX(Y)24,26,28M
STEP
Master unit
INV
Slave unit
INV
STD unit
No.1
STD unit
No.2
STD unit
No.3
1 52Hz OFF OFF OFF OFF
2 57Hz OFF OFF OFF OFF
3 62Hz OFF OFF OFF OFF
4 68Hz OFF OFF OFF OFF
5 74Hz OFF OFF OFF OFF
6 81Hz OFF OFF OFF OFF
7 88Hz OFF OFF OFF OFF
8 96Hz OFF OFF OFF OFF
9 104Hz OFF OFF OFF OFF
10 110Hz OFF OFF OFF OFF
11 116Hz OFF OFF OFF OFF
12 124Hz OFF OFF OFF OFF
13 133Hz OFF OFF OFF OFF
14 143Hz OFF OFF OFF OFF
15 158Hz OFF OFF OFF OFF
16 165Hz OFF OFF OFF OFF
17 177Hz OFF OFF OFF OFF
18 189Hz OFF OFF OFF OFF
19 202Hz OFF OFF OFF OFF
20 210Hz OFF OFF OFF OFF
21 52Hz 189Hz OFF OFF OFF
22 74Hz 189Hz OFF OFF OFF
23 96Hz 189Hz OFF OFF OFF
24 116Hz 189Hz OFF OFF OFF
25 133Hz 189Hz OFF OFF OFF
26 158Hz 189Hz OFF OFF OFF
27 177Hz 189Hz OFF OFF OFF
28 202Hz 189Hz OFF OFF OFF
29 210Hz 189Hz OFF OFF OFF
30 52Hz 189Hz ON OFF OFF
31 88Hz 189Hz ON OFF OFF
32 124Hz 189Hz ON OFF OFF
33 158Hz 189Hz ON OFF OFF
34 189Hz 189Hz ON OFF OFF
35 210Hz 189Hz ON OFF OFF
36 52Hz 189Hz ON ON OFF
37 88Hz 189Hz ON ON OFF
38 124Hz 189Hz ON ON OFF
39 158Hz 189Hz ON ON OFF
40 189Hz 189Hz ON ON OFF
41 210Hz 189Hz ON ON OFF
42 52Hz 189Hz ON ON ON
43 104Hz 189Hz ON ON ON
44 143Hz 189Hz ON ON ON
45 189Hz 189Hz ON ON ON
46 210Hz 189Hz ON ON ON
∗
• Compressors are operated in the order of descending priorities.
• Compressors may operate in a pattern other than those listed in above tables subject to the operating conditions.
•“Master unit”, and “slave unit” in this section are the names for control, and they will be transferred according to the
priority of rotation system.
