Refrigerant Circuit Si38-304
64 Refirgerant Circuit
1. Refrigerant Circuit
1.1 RXY5M
No. in
refrigerant
system
diagram
Symbol Name Major Function
A M1C Inverter compressor (INV)
Inverter compressor is operated on frequencies between 52 Hz and 210 Hz by using
the inverter. The number of operating steps is as follows when Inverter compressor is
operated.
RXY5M : 20 steps
D M1F Inverter fan
Since the system is of air heat exchanging type, the fan is operated at 8-step rotation
speed by using the inverter.
EY1E
Electronic expansion valve
(Main: EV1)
While in heating operation, PI control is applied to keep the outlet superheated degree
of air heat exchanger constant.
G Y1S Solenoid valve (Hot gas: SVP) Used to prevent the low pressure from transient falling.
JY2S
Solenoid valve (Receiver gas
discharging: SVG)
Used to collect refrigerant to receiver.
K Y4S Solenoid valve (Injection):SVT Used to control injection in order to prevent overheating.
M Y3S 4-way valve Used to switch the operation mode between cooling and heating.
N S1NPH High pressure sensor Used to detect high pressure.
O S1NPL Low pressure sensor Used to detect low pressure.
PS1PH
HP pressure switch (For INV
compressor)
In order to prevent the increase of high pressure when a malfunction occurs, this
switch is activated at high pressure of 2.7 MPA or more to stop the compressor
operation.
S — Fusible plug
In order to prevent the increase of pressure when abnormal heating is caused by fire
or others, the fusible part of the plug is molten at a temperature of 70 to 75°C to
release the pressure into the atmosphere.
T—
Pressure regulating valve 1
(Receiver to discharge pipe)
This valve opens at a pressure of 1.5 to 2.0 MPa for prevention of pressure increase,
thus resulting in no damage of functional parts due to the increase of pressure in
transportation or storage.
1 R1T Thermistor (Outdoor air: Ta) Used to detect outdoor temperature, correct discharge pipe temperature, and others.
2 R2T Thermistor (Suction pipe: Ts)
used to detect suction pipe temperature, keep the suction superheated degree
constant in heating operation, and others.
3 R31T
Thermistor (INV discharge
pipe: Tdi)
used to detect discharge pipe temperature, make the temperature protection control of
compressor, and others.
6R4T
Thermistor (Heat exchanger
deicer: Tb)
Used to detect liquid pipe temperature of air heat exchanger, determine defrosting
operation, and others.
7R5T
Thermistor (Receiver gas
pipe: Tsh)
Used to detect receiver gas pipe temperature in order to check the receiver to fill with
liquid refrigerant.
