Si38-304 Specifications
Specifications 47
Ceiling Mounted Low Silhouette Duct Type
Notes:
+
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
+
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
+
3 Indoor temp. : 20°CDB / outdoor temp.: 7°CDB, 6°CWB / Equivalent piping length; 7.5m, level difference;
0m. (Heat pump only)
4 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
+
5 Operation sound is measured in an anechoic chamber.
When the place of suction is changed to the bottom suction, the sound level will increase by approx. 5
dBA.
+
6 Model name for other country
+
6
Model
FXYD40KAVE FXYD50KAVE FXYD63KAVE
+
++
+
1 Cooling Capacity (19.5°CWB)
kcal/h 4,000 5,000 6,300
Btu/h 15,900 19,900 25,000
kW 4.7 5.8 7.3
+
++
+
2 Cooling Capacity (19.0°CWB) kW 4.5 5.6 7.1
+
++
+
3 Heating Capacity
kcal/h 4,300 5,400 6,900
Btu/h 17,000 21,500 27,300
kW 5.0 6.3 8.0
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 260×900×580 260×1,300×580 260×1,300×580
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 3×10×1.75 2×10×1.75 3×10×1.75
Face Area m² 0.147 0.231 0.231
Fan
Type Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output × Number
of Units
W 45×1 65×1 65×1
Air Flow Rate (H/L)
m³/min 12/11 17/15 17/15
cfm 424/388 600/530 600/530
External Static Pressure Pa 49 49 49
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Sound Absorbing Thermal Insulation Material Form Polyethylene Form Polyethylene Form Polyethylene
Piping
Connections
Liquid Pipes mm φ6.4 (Flare Connection) φ9.5 (Flare Connection) φ9.5 (Flare Connection)
Gas Pipes mm φ12.7 (Flare Connection) φ15.9 (Flare Connection) φ15.9 (Flare Connection)
Drain Pipe in. 3/4B 3/4B 3/4B
Machine Weight kg 24 31 32
+
++
+
5 Sound Level (H/L) dBA 38/35 41/38 41/38
Safety Devices
Fuse
Thermal Protector for Fan Motor
Fuse
Thermal Protector for Fan Motor
Fuse
Thermal Protector for Fan Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable Outdoor Unit R22 : K or M Series R22 : K or M Series R22 : K or M Series
Standard Accessories
Operation Manual, Installation
Manual, Clamp Metal, Insulation for
Fitting, Sealing Pads, Clamps, Screws
for Duct Flanges.
Operation Manual, Installation
Manual, Clamp Metal, Insulation for
Fitting, Sealing Pads, Clamps, Screws
for Duct Flanges.
Operation Manual, Installation
Manual, Clamp Metal, Insulation for
Fitting, Sealing Pads, Clamps, Screws
for Duct Flanges.
Drawing No. C : 3D024660
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
For General Country FXYD40KAVE FXYD50KAVE FXYD63KAVE
For Thailand FXYD40KVES FXYD50KVES FXYD63KVES
