Si38-304 Field Setting
Test Operation 141
∗
Setting No. 1, 5, 6 are the present status display only.
Display for malfunction/preparing/test-run
Display during low noise operation
Display during demand operation
No. Setting (displaying) item
LED display example
H1P H2P H3P H4P H5P H6P H7P
1
Display for malfunction /
preparing / test run
∗
7787777
2 C/H selector (individual)
7787777
3 C/H selector (Master)
7778777
4 C/H selector (Slave)
7777877
5 Low noise operation
∗
77
{
7777
6 Demand operation
∗
77
{
7777
Normal
7787777
Malfunction
7887777
Preparing/Test-run
7987777
Normal
7787777
During low noise operation
7787787
H3P to H5P LED
display changes
depending on
setting No. 2, 3, 4.
Normal
7787777
During demand operation
7787778
H3P to H5P LED
display changes
depending on
setting No. 2, 3, 4.
8
: ON
7
: OFF
9
: Blinking
a. “Setting mode 1”
<Selection of setting items>
Push the SET button (BS2) and set
LED display to a setting item you
want.
Regarding setting item No. 1,5,6,
only the present status is
displayed. For the respective
description, refer to the table
shown on lower right.
The cool/heat selection setting can
be changed on setting item 2, 3, 4.
→ After setting, push the RETURN
button (BS3) and decide the
item.
When the RETURN button (BS3) is
pushed, the status becomes the initial
status of “Setting mode 1”.
“Normally, “Setting mode 1” is set.
In case of other status, push MODE
button (BS1) one time and set to
“Setting mode 1”.
(V2763)
