Si38-304 Protection Control
Function 105
4. Protection Control
4.1 High Pressure Protection Control
This high pressure protection control is used to prevent the activation of protection devices due
to abnormal increase of high pressure and to protect compressors against the transient
increase of high pressure.
[In cooling operation]
+
In the case of multi-outdoor-unit system, each outdoor unit performs this control
individually in the following sequence.
[In heating operation]
+
In the case of multi-outdoor-unit system, the entire system performs this control in the
following sequence.
High pressure not limited
Pc>2.20MPa
High pressure standby
INV upper limit frequency = 210 Hz
High pressure limited
Pc>2.20MPa
Pc>2.30MPa
Pc<2.04MPa
Pc>2.25MPa
STD compressor
standby for 5 mins
Pc: HP pressure sensor detection
value for each outdoor unit
INV upper limit frequency :
3-step / 10 sec down from
current compressor frequency
INV upper limit frequency:
1-step / 20 sec up from
current compressor frequency
When occurring 10 times within 60
minutes for 5HP unit and 3 times
within 30 minutes for over 8HP units,
HPS is activated without high pressure
standby, thus outputting the
malfunction code "E3".
High pressure not limited
Pc>2.10
MPa
Lower-priority compressor stops.
High pressure limited
Pc>2.10
MPa
Master unit: 52 Hz + OFF + OFF
Slave unit: All units stop.
Pc>2.20
MPa
High pressure standby
Pc>2.30
MPa
Pc<1.96
MPa
Pc: HP pressure sensor detection
value for master unit
When occurring 10 times within 60 minutes for 5HP
and 3 times within 30 minutes for over 8HP units, HPS
is activated without high pressure standby, thus
outputting the malfunction code "E3".
