Si38-304 Specifications
Specifications 25
Notes:
+
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
+
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
+
3 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB / Equivalent piping length : 7.5m, level
difference : 0m.
Model Name (Combination Unit)
RXY30MYL(E)
RXY30MTL(E)
RXY32MYL(E)
RXY32MTL(E)
Model Name (Independent Unit)
RXY14MYL(E)+RXY16MYL(E)
RXY14MTL(E)+RXY16MTL(E)
RXY16MYL(E)+RXY16MYL(E)
RXY16MTL(E)+RXY16MTL(E)
+
1 Cooling Capacity (19.5°CWB)
kcal / h 75,500 80,000
Btu / h 299,000 316,000
kW 87.6 92.8
+
2 Cooling Capacity (19.0°CWB) kW 85.0 90.0
+
3 Heating Capacity
kcal / h 75,500 80,000
Btu / h 296,000 308,000
kW 86.5 90.0
Casing Color
YL, TL Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
YLE, TLE
Light Camel (2.5Y6.5/1.5) Light Camel (2.5Y6.5/1.5)
Dimensions: (H×W×D) mm (1600×1240×765)+(1600×1240×765) (1600×1240×765)+(1600×1240×765)
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston Displacement m³/h (19.36+14.68+14.68)×2 (19.36+14.68+14.68)×2
Number of Revolutions r.p.m (6480, 2900×2)×2 (6480, 2900×2)×2
Motor Output×Number
of Units
kW (2.0+4.5+4.5)+(3.0+4.5+4.5) (3.0+4.5+4.5)+(3.0+4.5+4.5)
Starting Method Direct on Line Direct on Line
Fan
Type Propeller Fan Propeller Fan
Motor Output kW 0.75×2 0.75×2
Air Flow Rate m³/min 210×2 210×2
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm φ22.2 (Brazing Connection) φ22.2 (Brazing Connection)
Gas Pipe mm φ41.3 (Brazing Connection) φ41.3 (Brazing Connection)
Oil Equalizing Pipe mm φ6.4 (Flare Connection) φ6.4 (Flare Connection)
Machine Weight kg 331+333 333+333
Safety Devices
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector,
Fusible Plugs
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector,
Fusible Plugs
Defrost Method Deicer Deicer
Capacity Control % 5~100 5~100
Refrigerant
Refrigerant Name R22 R22
Charge kg 17.1+18.6 18.6+18.6
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator
Oil
SUNISO 4GSDID-K SUNISO 4GSDID-K
Charge Volume L (1.9+1.6+1.6)+(1.9+1.6+1.6) (1.9+1.6+1.6)+(1.9+1.6+1.6)
Standard Accessories
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No.
YL(E) 4D038980, 4D038981 4D038981
TL(E) 4D038986, 4D038987 4D038987
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
