Si38-304 Specifications
Specifications 17
Notes:
+
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
+
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
+
3 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB / Equivalent piping length : 7.5m, level
difference : 0m.
Model Name (Combination Unit) RXY42MY1(E) RXY44MY1(E)
Model Name (Independent Unit) RXY10MY1(E)+RXY16MY1(E)+RXY16MY1(E) RXY12MY1(E)+RXY16MY1(E)+RXY16MY1(E)
+
1 Cooling Capacity (19.5°CWB)
kcal / h 105,000 110,000
Btu / h 415,000 434,000
kW 122 127
+
2 Cooling Capacity (19.0°CWB) kW 118 124
+
3 Heating Capacity
kcal / h 107,000 110,000
Btu / h 416,000 426,000
kW 122 125
Casing Color
Y1 Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
Y1E Light Camel (2.5Y6.5/1.5) Light Camel (2.5Y6.5/1.5)
Dimensions: (H×W×D) mm (1600×930×765)+(1600×1240×765)+(1600×1240×765) (1600×1240×765)+(1600×1240×765)+(1600×1240×765)
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston Displacement m³/h (19.36+14.68)+(19.36+14.68+14.68)×2 (19.36+14.68)+(19.36+14.68+14.68)×2
Number of Revolutions r.p.m (6480, 2900)+(6480, 2900×2)×2 (6480, 2900)+(6480, 2900×2)×2
Motor Output×Number
of Units
kW (2.75+4.5)+(3.0+4.5+4.5)×2 (4.2+4.5)+(3.0+4.5+4.5)×2
Starting Method Direct on Line Direct on Line
Fan
Type Propeller Fan Propeller Fan
Motor Output kW 0.75×3 0.75×3
Air Flow Rate m³/min 180+210+210 210+210+210
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm φ22.2 (Brazing Connection) φ22.2 (Brazing Connection)
Gas Pipe mm φ54.1 (Brazing Connection) φ54.1 (Brazing Connection)
Oil Equalizing Pipe mm φ6.4 (Flare Connection) φ6.4 (Flare Connection)
Machine Weight kg 235+333+333 290+333+333
Safety Devices
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector,
Fusible Plugs
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector,
Fusible Plugs
Defrost Method Deicer Deicer
Capacity Control % 4~100 4~100
Refrigerant
Refrigerant Name R22 R22
Charge kg 13.9+18.6+18.6 15.6+18.6+18.6
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator
Oil
SUNISO 4GSDID-K SUNISO 4GSDID-K
Charge Volume L (1.9+1.6)+(1.9+1.6+1.6)+(1.9+1.6+1.6) (1.9+1.6)+(1.9+1.6+1.6)+(1.9+1.6+1.6)
Standard Accessories
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No. 4D038972A, 4D038975A 4D038973A, 4D038975A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
