Specifications Si38-304
34 Specifications
Notes:
+
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
+
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
Model Name (Combination Unit) RX22MY1(E) RX24MY1(E)
Model Name (Independent Unit) RX10MY1(E)+RX12MY1(E) RX10MY1(E)+RX14MY1(E)
+
1 Cooling Capacity (19.5°CWB)
kcal / h 55,000 60,500
Btu / h 217,000 240,000
kW 63.4 70.1
+
2 Cooling Capacity (19.0°CWB) kW 61.5 68.0
Casing Color
Y1 Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
Y1E Light Camel (2.5Y6.5/1.5) Light Camel (2.5Y6.5/1.5)
Dimensions: (H×W×D) mm (1600×930×765)+(1600×1240×765) (1600×930×765)+(1600×1240×765)
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston Displacement m³/h (19.36+14.68)×2 (19.36+14.68)+(19.36+14.68+14.68)
Number of Revolutions r.p.m (6480, 2900)×2 (6480, 2900)+(6480, 2900×2)
Motor Output×Number
of Units
kW (2.75+4.5)+(4.2+4.5) (2.75+4.5)+(2.0+4.5+4.5)
Starting Method Direct on Line Direct on Line
Fan
Type Propeller Fan Propeller Fan
Motor Output kW 0.75×2 0.75×2
Air Flow Rate m³/min 180+210 180+210
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm φ19.1 (Brazing Connection) φ19.1 (Brazing Connection)
Gas Pipe mm φ34.9 (Brazing Connection) φ41.3 (Brazing Connection)
Oil Equalizing Pipe mm φ6.4 (Flare Connection) φ6.4 (Flare Connection)
Machine Weight kg
Safety Devices
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector,
Fusible Plugs
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector,
Fusible Plugs
Capacity Control % 7~100 6~100
Refrigerant
Refrigerant Name R22 R22
Charge kg 13.9+15.6 13.9+17.1
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator
Oil
SUNISO 4GSDID-K SUNISO 4GSDID-K
Charge Volume L (1.9+1.6)+(1.9+1.6) (1.9+1.6)+(1.9+1.6+1.6)
Standard Accessories
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No. 4D039037, 4D039038 4D039037, 4D039039
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
