Specifications Si38-304
42 Specifications
Ceiling Mounted Cassette Type (Double-flow)
Notes:
+
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
+
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
+
3 Indoor temp. : 20°CDB / outdoor temp.: 7°CDB, 6°CWB / Equivalent piping length; 7.5m, level difference;
0m. (Heat pump only)
4 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
+
5 Operation sound is measured in an anechoic chamber.
Model FXC50LVE FXC63LVE FXC80LVE FXC125LVE
+
++
+
1 Cooling Capacity (19.5°CWB)
kcal/h 5,000 6,300 8,000 12,500
Btu/h 19,900 25,000 31,800 49,600
kW 5.8 7.3 9.3 14.5
+
++
+
2 Cooling Capacity (19.0°CWB) kW 5.6 7.1 9.0 14.0
+
++
+
3 Heating Capacity
kcal/h 5,400 6,900 8,600 13,800
Btu/h 21,500 27,300 34,100 54,600
kW 6.3 8.0 10.0 16.0
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 305×995×600 305×1,180×600 305×1,670×600 305×1,670×600
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 2×10×1.5 2×10×1.5 2×10×1.5 2×10×1.5
Face Area m² 2×0.145 2×0.184 2×0.287 2×0.287
Fan
Model 2D17K1AA1 2D17K2AA1VE 3D17K2AA1 3D17K2AB1
Type Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output × Number
of Units
W 20×1 30×1 50×1 85×1
Air Flow Rate (H/L)
m³/min 12/9 16.5/13 26/21 33/25
cfm 424/318 582/459 918/741 1,165/883
Drive Direct Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Sound Absorbing Thermal Insulation Material Glass Wool/Urethane Foam Glass Wool/Urethane Foam Glass Wool/Urethane Foam Glass Wool/Urethane Foam
Piping
Connections
Liquid Pipes mm φ9.5 (Flare Connection) φ9.5 (Flare Connection) φ9.5 (Flare Connection) φ9.5 (Flare Connection)
Gas Pipes mm φ15.9 (Flare Connection) φ15.9 (Flare Connection) φ15.9 (Flare Connection) φ19.1 (Flare Connection)
Drain Pipe mm
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
Machine Weight kg 32 35 47 48
+
++
+
5 Sound Level (H/L) dBA 34/29 37/32 39/34 44/38
Safety Devices
Fuse, Thermal Protector for
Fan Motor
Fuse, Thermal Protector for
Fan Motor
Fuse, Thermal Protector for
Fan Motor
Fuse, Thermal Protector for
Fan Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable outdoor unit
R22 ; K or M Series
R407C ; K or L Series
R22 ; K or M Series
R407C ; K or L Series
R22 ; K or M Series
R407C ; K or L Series
R22 ; K or M Series
R407C ; K or L Series
Decoration
Panels
(Option)
Model
BYBC50G-W1 BYBC63G-W1 BYBC125G-W1 BYBC125G-W1
Panel Color White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5)
Dimensions: (H×W×D) mm 53×1,245×680 53×1,430×680 53×1,920×680 53×1,920×680
Air Filter
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Weight kg 8.5 9.5 12 12
Standard Accessories
Operation Manual,
Installation Manual, Paper
Pattern for Installation,
Washer for Hanging
Brackets, Clamp Metal,
Drain Hose, Insulation for
Fitting, Washer Fixing
Plates, Sealing Pads,
Clamps, Screws, Washers.
Operation Manual,
Installation Manual, Paper
Pattern for Installation,
Washer for Hanging
Brackets, Clamp Metal,
Drain Hose, Insulation for
Fitting, Washer Fixing
Plates, Sealing Pads,
Clamps, Screws, Washers.
Operation Manual,
Installation Manual, Paper
Pattern for Installation,
Washer for Hanging
Brackets, Clamp Metal,
Drain Hose, Insulation for
Fitting, Washer Fixing
Plates, Sealing Pads,
Clamps, Screws, Washers.
Operation Manual,
Installation Manual, Paper
Pattern for Installation,
Washer for Hanging
Brackets, Clamp Metal,
Drain Hose, Insulation for
Fitting, Washer Fixing
Plates, Sealing Pads,
Clamps, Screws, Washers.
Drawing No. 3D034244A
()()()()
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
