Si38-304 List of Electrical and Functional Parts
Appendix 307
Parts Name
Symbol
Model
Remark
FXK
25LVE
FXK
32LVE
FXK
40LVE
FXK
63LVE
Remote
Controller
Wired Remote
Controller
BRC1A61 Option
Wireless Remote
Controller
H/P BRC4C61, C/O BRC4C63
Motors
Fan Motor M1F
AC 220~240V 50Hz
1φ15W 4P 1φ20W 4P 1φ45W 4P
Thermal Fuse 146°C
Thermal protector 120°C : OFF 105°C :
ON
Drain Pump M1P
AC 220-240V (50Hz)
PLD-12200DM
Thermal Fuse 145°C
Swing Motor M1S
MP8-L [3PA07312-1]
AC200~240V
Thermistors
Thermistor (Suction Air)
R1T
ST8601-13 φ4 L630
20kΩ (25°C)
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-7 φ8 L1600
20kΩ (25°C)
Thermistor (Heat
Exchanger)
R2T
ST8602A-7 φ6 L1600
20kΩ (25°C)
Others
Float Switch S1L FS-0211B
Fuse F1U 250V 5A φ5.2
Transformer T1R TR22H21R8
Parts Name Symbol
Model
Remark
FXYD20
KAVE
FXYD25
KAVE
FXYD32
KAVE
FXYD40
KAVE
FXYD50
KAVE
FXYD63
KAVE
Remote
Controller
Wired Remote
Controller
BRC1A62 Option
Wireless Remote
Controller
H/P BRC4C62, C/O BRC4C64 Option
Motors Fan Motor M1F
AC 220~240V/220V 50/60Hz
1φ45W 1φ65W
Thermal Protector 135°C
Thermistors
Thermistor (Suction
Air)
R1T
ST8601-2 φ4 L400
20kΩ (25°C)
Thermistor (for Heat
Exchanger High
Temp.)
R3T
ST8605-2 φ8 L400
20kΩ (25°C)
Thermistor (Heat
Exchanger)
R2T
ST8602-2 φ6 L400
20kΩ (25°C)
Others
Float Switch 33H FS-0211
Fuse F1U 250V 10A φ5.2
Transformer T1R TR22M21R8
