Si38-304 List of Electrical and Functional Parts
Appendix 309
Parts Name
Symbol
Model
Remark
FXH
32LVE
FXH
63LVE
FXH
100LVE
Remote
Controller
Wired Remote
Controller
BRC1A61 Option
Wireless Controller H/P BRC7E63W, C/O BRC7E66
Motors
Fan Motor M1F
AC 220~240V/220V 50Hz/60Hz
1φ63W 1φ130W
Thermal protector 130°C : OFF 80°C : ON
Capacitor for Fan Motor
C1R 3.0µF-400V
9.0µF-400V
Swing Motor M1S
MT8-L[3P058751-1]
AC200~240V
Thermistors
Thermistor (Suction Air) R1T
ST8601A-1 φ4 L250
20kΩ (25°C)
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-6 φ8 L = 1250
20kΩ (25°C)
Thermistor (Heat
Exchanger)
R2T
ST8602A-6 φ6 L = 1250
20kΩ (25°C)
Others
Fuse F1U 250V 5A φ5.2
Transformer T1R TR22H21R8
Parts Name
Symbol
Model
Remark
FXA
20LVE
FXA
25LVE
FXA
32LVE
FXA
40LVE
FXA
50LVE
FXA
63LVE
Remote
Controller
Wired Remote
Controller
BRC1A61 Option
Wireless Remote
Controller
H/P BRC7E618, C/O BRC7E619 Option
Motors
Fan Motor M1F
AC 220~240V 50Hz
1φ40W 1φ43W
—
Swing Motor M1S
MP24[3SB40333-1]
AC200~240V
MSFBC20C21 [3SB40550-1]
AC200~240V
Thermistors
Thermistor (Suction Air)
R1T
ST8601-2 φ4 L400
20kΩ (25°C)
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-2 φ8 L400
20kΩ (25°C)
Thermistor (for Heat
Exchanger)
R2T
ST8602-2 φ6 L400
20kΩ (25°C)
Others
Float Switch S1L
OPTION
Fuse F1U 250V 5A φ5.2
