Selection of Pipe Size, Joints and Header Si38-304
320 Appendix
6.2.8 Piping between outdoor Unit and Multi Connection Piping Kit
Pipe size for direct connection to outdoor unit must be the same as the connection size of
outdoor unit.
6.2.9 The piping minimum thickness
∗ Select the wall thickness in accordance with revelant local and national regulations.
Outdoor Units Gas Liquid Oil
RXY8, 10MY1 φ28.6 φ12.7
φ6.4
RXY12-16MY1 φ34.9 φ15.9
R22
Size Material Minimum thickness
t (mm)
φ6.4 O 0.8
φ9.5 O 0.8
φ12.7 O 0.8
φ15.9 O 1.0
φ19.1 O 1.0
φ22.2 1/2H 1.0
φ25.4 1/2H 1.2
φ28.6 1/2H 1.2
φ34.9 1/2H 1.3
φ41.3 1/2H 1.7
φ54.1 1/2H 1.7
