Si38-304 Basic Control
Function 87
2. Basic Control
2.1 Normal Operation
Cooling Operation
Heating Operation
+
Heating operation is not functional at an outdoor air temperature of 25°C or more.
Actuator Operation Remarks
Compressor Compressor PI control
Used for high pressure protection control, low
pressure protection control, discharge pipe
temperature protection control, and compressor
operating frequency upper limit control with inverter
protection control.
Outdoor unit fan Cooling fan control
Four way valve OFF
Main motorized valve (EV1) 0 pls (RX(Y)5M : 2000pls)
Subcooling motorized valve (EV2) PI control
Hot gas bypass valve (SVP) OFF
This valve turns on with low pressure protection
control.
Oil equalization valve (SVO) ON
In the case of multi-outdoor-unit system, this valve
repeats ON/OFF operation at regular intervals of
time.
Receiver gas charging valve (SVL) OFF
This valve turns on when outdoor temperature is
low.
Receiver gas discharging valve (SVG) OFF
Non-operating unit gas discharging
valve (SVSG)
OFF
Non-operating unit liquid pipe stop valve
(SVSL)
ON
Actuator Operation Remarks
Compressor Compressor PI control
Used for high pressure protection control, low
pressure protection control, discharge pipe
temperature protection control, and compressor
operating frequency upper limit control with inverter
protection control.
Outdoor unit fan STEP8 or 9
Four way valve ON
Main motorized valve (EV1) PI control
Subcooling motorized valve (EV2) 0 pls
Hot gas bypass valve (SVP) OFF
This valve turns on with low pressure protection
control.
Oil equalization valve (SVO) ON
In the case of multi-outdoor-unit system, this valve
repeats ON/OFF operation at regular intervals of
time.
Receiver gas charging valve (SVL) OFF
Receiver gas discharging valve (SVG) OFF
Non-operating unit gas discharging
valve (SVSG)
OFF
Non-operating unit liquid pipe stop valve
(SVSL)
ON
