Specifications Si38-304
54 Specifications
Ceiling Mounted Duct Type
Notes:
+
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
+
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
+
3 Indoor temp. : 20°CDB / outdoor temp.: 7°CDB, 6°CWB / Equivalent piping length; 7.5m, level difference;
0m. (Heat pump only)
+
4 Static external pressure is changeable to change over the connectors inside electrical box, this pressure
means "High static pressure-Standard".
+
5 Air filter is not standard accessory, but please mount it in the duct system of the suction side. Select its
colorimetric method (gravity method) 50% or more.
6 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
+
7 Operation sound is measured in an anechoic chamber.
Model FXM40LVE FXM50LVE FXM63LVE FXM80LVE
+
1 Cooling Capacity (19.5°CWB)
kcal/h 4,000 5,000 6,300 8,000
Btu/h 15,900 19,900 25,000 31,800
kW 4.7 5.8 7.3 9.3
+
2 Cooling Capacity (19.0°CWB) kW 4.5 5.6 7.1 9.0
+
++
+
3 Heating Capacity
kcal/h 4,300 5,400 6,900 8,600
Btu/h 17,000 21,500 27,300 34,100
kW 5.0 6.3 8.0 10.0
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 390×720×690 390×720×690 390×720×690 390×1,110×690
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 3×16×2.0 3×16×2.0 3×16×2.0 3×16×2.0
Face Area m² 0.181 0.181 0.181 0.319
Fan
Model D11/2D3AB1VE D11/2D3AB1VE D11/2D3AA1VE 2D11/2D3AG1VE
Type Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output × Number
of Units
W 100×1 100×1 160×1 270×1
Air Flow Rate (H/L)
m³/min 14/11.5 14/11.5 19.5/16 29/23
cfm 494/406 494/406 688/565 1,024/812
External Static Pressure Pa 157/157-118/108
+
++
+
4 157/157-118/108
+
++
+
4 157/160-108/98
+
++
+
4 157/172-98/98
+
++
+
4
Drive Direct Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Sound Absorbing Thermal Insulation Material Glass Fiber Glass Fiber Glass Fiber Glass Fiber
Air Filter
+
++
+
5
+
++
+
5
+
++
+
5
+
++
+
5
Piping
Connections
Liquid Pipes mm φ6.4 (Flare Connection) φ9.5 (Flare Connection) φ9.5 (Flare Connection) φ9.5 (Flare Connection)
Gas Pipes mm φ12.7 (Flare Connection) φ15.9 (Flare Connection) φ15.9 (Flare Connection) φ15.9 (Flare Connection)
Drain Pipe mm
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
Machine Weight kg 44 44 45 62
+
++
+
7 Sound Level (H/L) dBA 39/35 39/35 42/38 43/39
Safety Devices
Fuse,
Thermal Fuse for Fan Motor
Fuse,
Thermal Fuse for Fan Motor
Fuse,
Thermal Fuse for Fan Motor
Fuse,
Thermal Fuse for Fan Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable outdoor unit
R22 ; K or M Series
R407C ; K or L Series
R22 ; K or M Series
R407C ; K or L Series
R22 ; K or M Series
R407C ; K or L Series
R22 ; K or M Series
R407C ; K or L Series
Standard Accessories
Operation Manual,
Installation Manual, Drain
Hose, Clamp Metal,
Insulation for Fitting, Sealing
Pads, Clamps, Screws.
Operation Manual,
Installation Manual, Drain
Hose, Clamp Metal,
Insulation for Fitting, Sealing
Pads, Clamps, Screws.
Operation Manual,
Installation Manual, Drain
Hose, Clamp Metal,
Insulation for Fitting, Sealing
Pads, Clamps, Screws.
Operation Manual,
Installation Manual, Drain
Hose, Clamp Metal,
Insulation for Fitting, Sealing
Pads, Clamps, Screws.
Drawing No. 3D034584A
()()()()
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
