Si38-304 List of Electrical and Functional Parts
Appendix 303
Item Name Symbol
Model
RXY12MTL RXY14MTL RXY16MTL
Compressor Inverter Type M1C JT100FBVDKT
4.2kW
JT100FBVDKT
2.0kW
JT100FBVDKT
3.0kW
Output
STD.1 Type M2C JT170FBK
4.5kW
JT170FBK
4.5kW
JT170FBK
4.5kW
Output
STD.2 Type M3C — JT170FBK
4.5kW
JT170FBK
4.5kW
Output
Crankcase heater (INV) E1HC 200V 33W
Crankcase heater (STD.1) E2HC 200V 33W
Crankcase heater (STD.2) E3HC — 200V 33W
OC protection device for STD
compressor
— 25A
Fan motor Motor M1F 0.80kw
Functional parts Electronic expansion
valve (Main)
Cooling Y1E 0pls
Heating PI control
Electronic expansion
valve (Subcool)
Cooling Y2E PI control
Heating 0pls
Solenoid valve (Hot gas) Y1S VPV-603D TEV1620DQ2
Solenoid valve (External multi oil) Y2S TEV1620DQ2
Solenoid valve (Receiver gas
charge)
Y3S TEV1620DQ2
Solenoid valve (Receiver gas
discharge)
Y4S VPV-603D
Solenoid valve (Non-operating
unit gas discharge)
Y5S TEV1620DQ2
Solenoid valve (Non-operating
unit liquid pipe close)
Y6S VPV-803DQ50
4 way valve Y7S VHV-0404 VT60100
Pressure-
related parts
Pressure switch (INV) S1PH PS80 ON : 2.7+0/-0.1MPa OFF : 1.9±0.15MPa
Pressure switch (STD1) S2PH PS80 ON : 2.7+0/-0.1MPa OFF : 1.9±0.15MPa
Pressure switch (STD2) S3PH — PS80
ON : 2.7+0/-0.1MPa
OFF : 1.9±0.15MPa
Fusible plug — FPGH-3D 70 to 75°c
Pressure sensor (HP) S1NPH PS8050A 0 to 3.33MPa
Pressure sensor (LP) S1NPL PS8050A -0.05 to 0.98MPa
Thermistor INV
PCB
For fin R1T 3.5 to 360Ω
Main
PCB
For outdoor air R1T 3.5 to 360Ω
For suction pipe R2T 3.5 to 360Ω
For discharge pipe
(INV)
R31T 3.5 to 400Ω
For discharge pipe
(STD.1)
R32T 3.5 to 400Ω
For discharge pipe
(STD.2)
R33T — 3.5 to 400Ω
For heat exchanger R4T 3.5 to 360Ω
For subcooling heat
exchanger
R5T 3.5 to 360Ω
For receiver liquid pipe R6T 3.5 to 360Ω
For equalizing pipe R7T 3.5 to 360Ω
Others Fuse (A1P) F1, 2U 250VAC 10A
Fuse (A4P) F1U 250VAC 5A
