Daikin RWEYQ26PY1 [115/342] Check of normal operation
![Daikin RWEYQ28PY1 [115/342] Check of normal operation](/views2/1713850/page115/bg73.png)
Test Operation Si30-813
104 Test Operation
1.1.4 Check of Normal Operation
After the check operation is completed, operate the unit normally.
(Heating is not possible if the outdoor temperature is 24°C or higher. Refer to the Operation
manual.)
Check the below items.
z
Make sure the indoor and outside units are operating normally (If a knocking sound can be
heard in the liquid compression of the compressor, stop the unit immediately and then
energize the heater for a sufficient length of time before restarting the operation.)
z
Run each indoor unit one at a time and make sure the corresponding outside unit is also
running.
z
Check if cold (or hot) air is coming out of the indoor unit.
z
Press the fan direction and fan strength buttons on the indoor unit to check if they operate
properly.
Caution <Cautions for normal operation check>
z
Once stopping, the compressor will not restart in about 5 minutes even if the Run/Stop
button of an indoor unit in the same system is pressed.
z
When the system operation is stopped by the remote controller, the outside units may
continue operating for further 5 minutes at maximum.
z
If the system has not undergone any check operation by the test operation button since it
was first installed, an malfunction code “U3” is displayed. In this case, perform check
operation referring to “1.1.3 Check Operation”.
z
After the test run, when handing the unit over to the customer, make sure the EL. COMPO.
BOX cover, the inspection door, and the unit casing are all attached.
