5-20
Chapter 5: BIOS Setup
LTR Mechanism Enable [Disabled]
Ifsupportedbyhardwareandsetto‘Enabled’,thisenablestheLatencyTolerance
Reporting (LTR) Mechanism.
Congurationoptions:[Disabled][Enabled]
End-End TLP Prefix Blocking [Disabled]
Ifsupportedbyhardwareandsetto‘Enabled’,thisfunctionwillblockforwardingof
TLPscontainingEnd-EndTLPPrexes.
Congurationoptions:[Disabled][Enabled]
PCI Express GEN2 Link Register
Target Link Speed [Auto]
Congurationoptions:[Auto][Forceto2.5GT/s][Forceto5.0GT/s][Forceto8.0GT/s]
[Forceto16.0GT/s]
Clock Power Management [Disabled]
Congurationoptions:[Disabled][Enabled]
Compliance SOS [Disabled]
Congurationoptions:[Disabled][Enabled]
Hardware Autonomous Width [Enabled]
Congurationoptions:[Enabled][Disabled]
Hardware Autonomous Speed [Enabled]
Congurationoptions:[Enabled][Disabled]
PCIE OPROM Slot Options
CPU1_PCIE1-3 Slot OPROM [Enabled]
This option allows you to enable or disable the OPROM of the PCIe slots.
Congurationoptions:[Disabled][Enabled]
CPU2_PCIE3 Slot OPROM [Enabled]
This option allows you to enable or disable the OPROM of the PCIe slots.
Congurationoptions:[Disabled][Enabled]
