Asus ESC4000 DHD G4 [35/178] Cpuconfigurationwith1dcpmmdimm asymmetricpopulation

2-11

ASUS ESC4000 DHD G4

AD - APP DIRECT MODE

DRAM1 - RDIMM, RDIMM 3DS, LRDIMM, LRDIMM 3DS

DCPMM - DC PERSISTENT MEMORY

1CPUCongurationwith1DCPMMDIMM(asymmetricpopulation)

Asymmetric Population (2nd Socket has no DCPMM DIMM)

Modes DIMM_C1 DIMM_B1 DIMM_A2 DIMM_A1

AD DRAM 1 DRAM 1 DCPMM DRAM 1

Asymmetric Population (2nd Socket has no DCPMM DIMM)

Modes DIMM_F1 DIMM_E1 DIMM_D2 DIMM_D1

AD DRAM 1 DRAM 1 DRAM 1

AD - APP DIRECT MODE

DRAM1 - RDIMM, RDIMM 3DS, LRDIMM, LRDIMM 3DS

DCPMM - DC PERSISTENT MEMORY

2CPUCongurationwith1DCPMMDIMM(asymmetricpopulation)

Asymmetric Population (2nd Socket has no DCPMM DIMM)

Modes DIMM_C1 DIMM_B1 DIMM_A2 DIMM_A1

AD DRAM 1 DRAM 1 DCPMM DRAM 1

Asymmetric Population (2nd Socket has no DCPMM DIMM)

Modes DIMM_F1 DIMM_E1 DIMM_D2 DIMM_D1

AD DRAM 1 DRAM 1 DRAM 1

Asymmetric Population (2nd Socket has no DCPMM DIMM)

Modes DIMM_J1 DIMM_H1 DIMM_G2 DIMM_G1

AD DRAM 1 DRAM 1 DRAM 1

Asymmetric Population (2nd Socket has no DCPMM DIMM)

Modes DIMM_M1 DIMM_L1 DIMM_K2 DIMM_K1

AD DRAM 1 DRAM 1 DRAM 1
