Chapter 3: Installation Options

3-2

Rear of Enclosure

Cabinet Depth

Rear Mounting

Flange

Keep-out

Zone for Rail

Keep-out

Zone for Rail

CMA

Front of Enclosure Front Mounting Flange

1.38” for Handle

3.1 Rail Kit

The rail kit package includes:

2 x 1200 mm rack rails

2 x M4X4L screws

8 x #10-32 screws

Rack

2 x M5X20L screws

Rear end

Front end

Rack rails

• Thebundledscrewpackageincludesdifferenttypesofscrewsforyoutochoosefrom,

notallscrewsarerequiredfortheinstallation.

• Packagecontentandspecicationsaresubjecttochangewithoutnotice.

EvenwithoutaCMA,another9”ofadditionalkeep-outzoneshouldbereservedbehindthe

inner rail. No obstructions such as power cables or sockets should be present in this keep-

outzone.

3.1.1 Selecting rack rail cabinets

Refertotheguidebelowformoreinformationonselectingarackrailcabinetandrackrailfor

yourserversystem.

1200 mm rack rail with CMA

A=700.3mm(27.6”)~965.5mm(38”)

A+B>1140mm(44.9”)

1200 mm rack rail without CMA

A=700.3mm(27.6”)~965.5mm(38”)

A+B>1040mm(41.0”)

8 x ø7.1 screws
