ASUS ESC4000 DHD G4
1-5
ModelName
ESC4000 DHD G4
Disk
Controller
SATAController
Intel
®
LewisburgPCH
- 4 x SATA3 6Gb/s ports or 4 x NVMe drives + 4 x M.2
connector PCI-E Gen3 x4 link
Intel
®
RSTe
(Supports software RAID 0, 1, 10 & 5)
Intel
®
VROC
(Supports software RAID 0, 1, 10 & 5)
Storage
Bays
I = internal
AorSwillbehot-
swappable
4 x 2.5" Hot-swap Storage Bays
PCIeNVMERiser
Card&Cable
Port to port Cable
Networking
2 x Intel X550 10G LAN ports
1 x Management LAN Port
2 x up to 100G NIC port (LP, HL), optional
VGA
Aspeed AST2500 64MB
Graphic
Up to 4 double deck GPU Cards
FrontI/OPorts
1 x Q-Code/Port 80 LED
2 x USB 3.2 Gen1 ports
RearI/OPorts
2 x USB 3.2 Gen1 ports
2 x RJ-45 10GbE LAN ports
1 x RJ-45 Mgmt LAN port
1 x VGA port
Switch/LED
FrontSwitch/LED:
1 x Power switch/LED
4 x M.2 access LEDs
1 x Reset switch
1 x Storage Device Access LED
1 x Message LED
2 x LAN LEDs
1 x Q code LCD
RearSwitch/LED:
1 x Message LED
1 x Storage Device LED
1 x Location LED
(continued on the next page)
