5-33
ASUS ESC4000 DHD G4
Memory RAS Conguration
Mirror Mode [Disabled]
Allows you to select Mirror Modes. Mirror Mode will set entire 1LM/2LM memory in
systemtobemirrored,consequentlyreducingthememorycapacitybyhalf.Enabling
MirrorModewilldisableXPTPrefetch.
Congurationoptions:[Disabled][MirrorMode1LM][MirrorMode2LM]
Enable Partial Mirror [Disabled]
Partialmirrormodewillenabletherequiredsizeofmemorytobemirrored.Ifrank
sparingisenabledpartialmirroringwillnottakeeffect.MirrorEnablewilldisableXPT
Prefetch.
Congurationoptions:[Disabled][PartialMirrormode1LM][PartialMirrormode2LM]
The following items appear only when the Enable Partial Mirror is set to [Partial Mirror
mode 1LM] or [Partial Mirror mode 2LM].
Partial Mirror1-4 Size in GB [0]
Select a multiplier of 1 GB for the size of the SAD to be created.
Congurationoptions:[0]~[422]
UEFI ARM Mirror [Disabled]
Allows you to enable or disable UEFI ARM Mirror.
Congurationoptions:[Disabled][Enabled]
Memory Rank Sparing [Disabled]
AllowsyoutoenableordisableMemoryRankSparing
Congurationoptions:[Disabled][Enabled]
Patrol Scrub [Enabled]
Allows you to enable or disable Patrol Scrub.
Congurationoptions:[Disabled][Enabled]
NGN Conguration
Average Power Budget (in mW) [18000]
Allowsyoutosetthepowermanagementpolicyforaveragepowerin250mW
increments.
Congurationoptions:[10000]-[18000]
