Chapter 1: Product Introduction
1-10
1.7.3 LAN(RJ-45)LEDs
LAN1/LAN2LEDs
DedicatedManagementLAN(forASMB9andDM_LAN1)
ACT/LINKLED SPEEDLED
Status Description Status Description
OFF No link OFF 10 Mbps connection
GREEN Linked ORANGE 100 Mbps connection
BLINKING Data activity GREEN 1 Gbps connection
ACT/LINKLED SPEEDLED
Status Description Status Description
OFF No link OFF 10 Mbps connection
ORANGE Linked ORANGE 100 Mbps connection
BLINKING Data activity GREEN 1 Gbps connection
ACT/LINKLED SPEEDLED
SPEEDLEDACT/LINKLED
