Asus ESC4000 DHD G4 [42/178] Expansion slots

Chapter 2: Hardware Setup

2-18

2.5 Expansion slots

Ensure to unplug the power cord before adding or removing expansion cards. Failure to do

so may cause you physical injury and damage motherboard components.

Riser card 1 Riser card 5

Riser card 2 Riser card 3 Riser card 4
