5-29
ASUS ESC4000 DHD G4
5.7.1 Processor Conguration
Per -Socket Conguration
AllowsyoutoconguresettingsfortheCPUsocket.
Hyper Threading [ALL] [Enabled]
AllowsyoutoenableordisabletheHyper-ThreadingTechnologyfunction.Whendisabled,
only one thread per activated core is enabled.
Congurationoptions:[Disabled][Enabled]
Enable Intel(R) TXT [Disabled]
ForcestheXDfeaturelogtoalwaysreturn0whendisabled.
Congurationoptions:[Disabled][Enabled]
VMX [Enabled]
EnablestheVanderpoolTechnology.Takeseffectafterreboot.
Congurationoptions:[Disabled][Enabled]
Enable SMX [Disabled]
Enables the Safer Mode Extensions.
Congurationoptions:[Disabled][Enabled]
Hardware Prefetcher [Enabled]
This Item allows you to turn on/off the mid level cache(L2) streamer prefetcher.
Congurationoptions:[Disabled][Enabled]
L2 RFO Prefetch Disable [Disabled]
This Item allows you to turn on/off L2 RFO prefetcher.
Congurationoptions:[Disabled][Enabled]
