Chapter 1: Product Introduction
1-8
The barebone server does not include a oppy disk drive or an optical drive. Connect a
USB oppy disk drive to any of the USB ports on the front or rear panel if you need to use
a oppy disk.
WARNING
HAZARDOUS MOVING PARTS
KEEP FINGERS AND OTHER BODY PARTS AWAY
A protection lm is pre-attached to the front cover before shipping. Please remove the
protection lm before turning on the system for proper heat dissipation.
1. Redundant power supply
and power fan
2. ASUS Z11PG-D16-HD
server board
3. System fans
4. Storage device trays
5. PCI-E x16 slots
(Gen3 x16 Link)
6. Low-prole PCI-E x16
slots with riser card
(Gen3 x16 Link)
1.6 Internalfeatures
The barebone server includes the basic components as shown.
