Chapter 1: Product Introduction
1-4
1.3 Systemspecications
The ASUS ESC4000 DHD G4 server features the ASUS Z11PG-D16-HD Series server board
that supports Intel
®
LGA 3647 Xeon
®
processor from the Skylake F and Skylake-SP product
family.
ModelName
ESC4000 DHD G4
Processor
2 x Socket P (LGA 3647)
1st and 2nd Gen Intel
®
Xeon
®
Processor Scalable Family (150W)*
UPI 10.4 GT/s
* Refer to support page for more information
Chipset
Intel
®
C621 PCH
Memory
Total Slots
16 (6-channel per CPU, 8 DIMM per CPU)
Capacity
Maximum up to 2048GB
MemoryType
DDR4 2933* (1 DIMM per Channel)
DDR4 2666/2400/2133 RDIMM/LRDIMM/LRDIMM 3DS
(2DIMM per Channel)
Intel
®
Optane™ DC persistent memory (DCPMM)
* 2933MHzwilldropto2666MHzwhenusing2DPCcongurations
**RefertoASUSserverAVLforthelatestupdate
MemorySize
32GB, 16GB, 8GB, 4GB (RDIMM)
64GB, 32GB (LRDIMM)
128GB, 64GB (LRDIMM/RDIMM 3DS)
* RefertoASUSserverAVLforthelatestupdate
Expansion
Slots
TotalPCI/PCI-X/
PCI-ESlots
6
Slot Type
4 x PCI-E x16 (Gen3 x16 Link)
Low-prole(Rear):
2 x Gen3 x16 Link
(continued on the next page)
