VM5404HA / VM5808HA User Manual
88
Mute Command
Mute allows you to enable or disable an output port(s) audio.
The formula for the Mute command is as follows:
Command + Output + Number + Control + [Enter]
1. For example, to mute the audio coming from output port 1, type:
mute o01 on [enter]
The following tables show the possible values for the Mute command:
Note: 1. Each command string can be separated with a space.
2. Skip the output port command to mute or enable the audio of all
output ports.
The following table lists the available Mute commands:
Command Description
mute Mute command
Output Command Description
o Output command
Port number Description
yy 01-08 port (default is 01)
* All output ports
Control Description
on Mute on; audio from HDMI output port
is disabled
off Mute off; audio output enabled
(default)
Command
Output
Command
Output
Port
Control Enter Description
mute
o yy
*
on [Enter] Audio on for output port yy
(yy:01~08, *)
mute
o yy
*
off [Enter] Audio off for output port yy
(default)
(yy:01~08, *)
