Chapter 5. CLI Commands
91
Note: 1. Each command string can be separated with a space.
2. The Port Number command string can be skipped, and the default
value will be used.
The following table lists the available Scaling commands:
Resolution Number Description
vvvv Vertical resolution
Frequency Description
freq Frequency command for scaling
Frequency Number Description
fff Frequency resolution
Control Description
off Turn off the scaling function
(by pass mode)
native Map display's native resolution for
scaling (default)
Command Output
Port
Number
Horizo-
ntal
Resolu-
tion
Number
Vertical
Resolu-
tion
Number Frequency Number Control Enter Description
scaling o yy
*
off [Enter] Turn off scaling
for port yy (by
pass mode)
yy: 01 ~ 08 or *
scaling o yy
*
native [Enter] Enable display’s
native resolution
for scaling on
output port yy
(default)
yy: 01 ~ 08 or *
scaling o yy
*
hor 1920 ver 1080 freq 60 [Enter] Scale output port
yy to
1920x1080@60H
z
yy: 01 ~ 08 or *
scaling o yy
*
hor 1280 ver 720 freq 60 [Enter] Scale output port
yy to
1280x720@60Hz
yy: 01 ~ 08 or *
scaling o yy
*
hor 1920 ver 1200 freq 60 [Enter] Scale output port
yy to
1920x1200@60H
z
yy: 01 ~ 08 or *
