Aten VM5808HA [28/124] Gateway

VM5404HA / VM5808HA User Manual

Gateway

To view the VM5404HA / VM5808HA’s gateway address, do the following:

1. From the Menu page, press 1 to see the IP Setting submenu, then press 8 or

Next to get to the next page. The gateway address displays.

Note: The default Gateway is 192.168.0.1.

2. Press 7 or Prev to go to the previous page.

3. Press Menu to return to the Menu page.

4. Press Cancel to return to the previous level of menu.

Gateway: 192.168.0.1

7: Back
