Aten VM5808HA [62/124] System settings

VM5404HA / VM5808HA User Manual

System Settings

In the web console, click the Settings icon from the Main page for the

System Settings to open on the General page:

The table below provides an overview of the available settings for each tab.

Tab Supported Functions Detailed Information

General



Configure the device name.



Select the interface language.



Monitor the video matrix’s fan

temperature and configure the fan

speed.



Configure the baud rate for serial

communications.

For more information,

see General, page 52.
