Aten VM5808HA [49/124] Profile scheduling is located below the profile list scheduling allows you to queue and play connection profiles in sequence for a specific amount of time

Chapter 4. Browser Operation

Profile Scheduling

Profile Scheduling is located below the Profile List. Scheduling allows you to

queue and play connection profiles in sequence for a specific amount of time.

Option Description

Click to edit profile schedule.

Click to play profile schedule.

Click to stop profile schedule. This option will only be available after

you click .

Click to change to next or previous profile when a profile schedule is

playing.
