VM5404HA / VM5808HA User Manual
14
LCD Menu Organization
The VM5404HA / VM5808HA has a built-in configuration utility via the front
panel LCD, which can be controlled by pressing the MENU and front panel
Input pushbuttons (1–8) or (1–4). User can cycle through the menu options,
starting from IP Setting page, in the order shown in the table below:
Note: The highlighted values are the default settings of the VM5404HA /
VM5808HA.
Menu Page Sub-Menu Page(s)
IP Setting IP Address
Subnet Mask
Gateway
Serial Port Setting Baud Rate 9600 / 19200 / 38400 / 115200
Operation Mode EDID Default / Port1 / Remix / Customized
CEC On / NA
OSD On / NA
Output Status Video On / NA
Audio Extract
Mute
01 - 04 (VM5404HA)
01 - 08 (VM5808HA)
On / NA
Output
Resolution
01-04 (VM5404HA);
01-08 (VM5808HA)
Array Mode (HDMI Out) Moded Single / Side by Side /
Quad View / Show All /
Manual
Selected
Input(s)
01 - 04 (VM5404HA)
01 - 08 (VM5808HA)
Security Mode Mode None
Password Enable
Lock Screen
Change Password Old Password New Password
Save to a Profile Save to a Profile No. 01–08 (VM5404HA); 01-16 (VM5808HA)
Play/Stop the Profile Schedule
Turn Video Wall Off
