Aten VM5808HA [16/124] Supported browsers

VM5404HA / VM5808HA User Manual

Supported Browsers

Use the recommended web browsers below to access the VM5404HA /

VM5808HA’s web console.

OS Java Version Browser Version

Windows 10_1903 x64 1.8.0_201 x64 Edge 44.18362.1.0

Firefox 68.0 x64

Chrome 75.0.3770.100 x64

Opera 62.0.3331.43 x64

Windows 8.1 x32 1.8.0_201 IE 11

Windows 2019_1809

DataCenter x64

1.8.0_201 x64 IE 11 x64

Windows 2016 x64 1.8.0_201 x64 IE 11 x64

Windows 7 SP1 x64 1.8.0_201 x64 IE 11 x64

CentOS 7.5 x64 Kernel

4.18.11-1

1.8.0_201 x64 Firefox 60.7.2-1 x64

Ubuntu 18.04 x64 Kernel

4.19.041900rc3

1.8.0_201 x64 Chrome 75.0.3770.100-1 x64

Solaris 11.4 x64 5.11 1.8.0.181 x64 Firefox 52.9.0 x32

MAC 11.4 - Safari 8

Windows 10 x64 1.8.0_201 x64 QQ 10.4.3587.400.

Windows 10 x64 1.8.0_201 x64 360 10.0.1508.0
