Aten VM5808HA [56/124] Display preferences

VM5404HA / VM5808HA User Manual

Display Preferences

Option Description

Output This indicates the selected displays.

Video Input Click to select a video source for the output(s). The chosen video

source (port number) is indicated at the center of the output(s) in the

preview.

Radio Button



Fit Width of Output(s): fits the video to the width of the display.



Fit Height of Output(s): fits the video to the height of the display.



Scale to Whole Output(s): fits the video on the entire display.
