Chapter 5. CLI Commands
85
Command Verification
After entering a command, a verification message appears at the end of the
command line as follows:
Command OK - indicates that the command is correct and successfully
performed by the switch
Command incorrect - indicates that the command has the wrong format
and/or values.
Commands
After connecting to the VM5404HA / VM5808HA via Telnet or RS-232, you
can operate the system using the following commands.
Switch Port Command
The Switch Port command allows you to switch ports on the VM5404HA /
VM5808HA.
The formula for the Switch command is as follows:
Command + Input + Number + Output + Number + Control + [Enter]
1. For example, to switch input port 02 to output port 05, type:
sw i02 o05 [Enter]
2. To switch output port 04 to the next port, type:
sw o04 + [Enter]
3. To turn off video output on port 03, type:
sw o03 off [Enter]
The following tables show the possible values for the Switch Port command:
Command Description
sw Switch command
Input Command Description
i Input command
Port number Description
xx 01-08 port
