Aten VM5808HA [39/124] Play stop the profile schedule

Chapter 3. Front Panel Configuration

Play/Stop the Profile Schedule

Inputting port pushbutton 2 will Play or Stop the active Profile Schedule.

Turn Video Wall Off

If a video wall is currently playing, a submenu will appear.

 Selecting Turn video wall off will return port assignments to their default

(i.e. disassemble the video wall).

1: Save to a Prole

2: Play/Stop the Prole Schedule

7: Back

1: Turn video wall o

7: Back
