Chapter 5. CLI Commands
93
Fan Speed Command
The Fan Speed command allows you to set the internal fan speed that cools the
VM5404HA/VM5808HA.
To set the fan speed, use the following command:
Command + Control + [Enter]
1. For example, to set the fan to low speed, type:
fan low [Enter]
The following tables show the possible values for the Fan Speed command:
Note: Each command string can be separated with a space.
The following table lists the available Fan Speed commands:
Command Description
fan Fan Speed Command
Control Description
low Set internal fan to low speed (default)
mid Set internal fan to normal speed
high Set internal fan to high speed
Command Control Enter Description
fan low [Enter] Sets fan speed to low
fan mid [Enter] Sets fan speed to normal
fan high [Enter] Sets fan speed to high
