Aten VM5808HA [70/124] Edid settings

VM5404HA / VM5808HA User Manual

EDID Settings

The EDID Setting page lets users view and select an EDID Mode so that the

VM5404HA / VM5808HA can use the best resolution for its displays.

Note: The EDID Mode can also be selected via the Front Panel pushbuttons –

see Operation Mode, page 18.

Extended Display Identification Data (EDID) is a data format that contains a

display's basic information and is used to communicate with the video source/

system.
