Aten VM5808HA [45/124] Importing a profile

Chapter 4. Browser Operation

Deleting a Profile

To delete a connection profile, do the following:

1. From the Profile List, click .

2. From the Profile List, click on the top-right corner of the profile you

want to remove.

3. A warning message appears and click OK.

Exporting a Profile

To export the matrix switch’s connection profiles, click Export Profiles. A

configuration file will then begin downloading.

Importing a Profile

To import connection profiles to the matrix switch, do the following:

1. Click Import Profiles.
