VM5404HA / VM5808HA User Manual

3. You can choose either the Normal View or the Grid View to edit the

profile.

Normal View

 On top of video and audio assignments, the Normal View also allows

you to configure the number of monitors and the bezel dimensions of

the profile.

 For detailed information, see Configuring Video Settings in Normal

View, page 42.

Grid View

 In Grid View, the audio and video outputs are assigned by mapping the

audio / video input on the vertical axis to the audio / video output on a

horizontal axis.
