Symbol Meaning
Wear protective boots�
Do not work in rain.
Keep hands and feet away
from rotating blades or cut-
ting line�
Caution! Possible injury from
rotating blade (disc, blade,
etc�)�
Movement direction�
Rotation direction�
Locked.
Unlocked.
Attention� Hot surfaces�
Do not smoke, keep sparks
and open ames from the
area while adding fuel or
operating the tool�
Beware of the ying object.
Beware of the kickback.
During operation no by-
standers or animals are al-
lowed within 15 m�
Attention. Important.
Symbol Meaning
A sign certifying that the
product complies with es-
sential requirements of the
EU directives and harmo-
nized EU standards.
Useful information�
Do not dispose of the tool in
a domestic waste container�
Tool designation
Grass trimmers are intended for grass mowing on
garden plots. Petrol engine makes them mobile (no
need to connect them to electric network).
The special features of the grass trimmers are their low
weight and maneuverability that enables to operate in
out-of-way areas and within conned spaces.
Design of the tool allows for using either a cutting
line or a cutting disc thus considerably expanding the
scope of application of the tool�
The tool is designed for right-handed users only�
Tool components
1 Throttle trigger
2 Throttle trigger locking button
3 On / off switch
4 Throttle interlock
5 Additional handle
6 Fastening (assembled)
7 Carrying belt fastening
8 Tube (assembled)
9 Engine
10 Fastening of the protective cover
11 Protective cover (assembled)
12 Angle transmission
13 Spool with the cutting line (assembled) *
14 Spark plug cap
15 Starter cord
16 Air throttle control lever
17 Air lter enclosure
18 Fuel tank plug
19 Fuel tank
20 Carrying belt *
21 Cutting disc *
22 Container for preparation of fuel mixture *
23 Allen key (4 mm) *
24 Allen key (5 mm) *
25 Wrench *
26 Multi-purpose wrench *
27 Additional handle bolts
28 Protective cover screw
29 Knife for shorten the cutting line *
30 Cover
31 Inner ange
32 Spindle
