15
English
33 Outer ange
34 Nut
35 Cap
36 Clamping screw
37 Fuel pump button
38 Fuel pipe
39 Spool cover *
40 Spool *
41 Spring *
42 Spool body *
43 Screw cap
44 Special bolt
45 Air lter cap
46 Air lter *
47 Spark plug *
48 Clamping screw
49 Spring pin
* Optional extra
Not all of the accessories illustrated or described
are included as standard delivery.
Installation and regulation of tool ele-
ments
Switch off the tool and remove the cap from the
spark plug before fullling all procedures.
Do not draw up the fastening elements
too tight to avoid damaging the thread.
Assembling / disassemling of the tube (see g. 1)
• When assembling, connect the two parts of the
tube 8, as shown in gure 1.1, and tighten the clamping
screw 48�
• When disassembling, loosen the clamping screw 48,
and then press on the spring pin 49 and separate the
two parts of the tube 8 (see g. 1.2).
Mounting / demounting of the additional handle
and adjusting of its position (see g. 2)
• Mount fastening 6 on tube 8 with the help of bolts 27
(see g. 2.1), tighten two lower bolts with a Allen key 23�
• Insert two halves of additional handle 5 into
fastening 6 (see g. 2.1) and tighten four upper bolts
with the Allen key 23�
• Disassembly operations do in reverse sequence�
• To adjust angle of inclination of additional handle 5,
loosen four upper bolts 27 and change the angle of
inclination (see g. 2.2). After nishing the adjustment
tighten bolts 27�
Mounting / demounting of the protective cover
(see g. 3)
• Mount protective cover 11 on fastening 10 and x with
the help of screws 28 (see g. 3). Tighten screws 28
with a screwdriver on multi-purpose wrench 26�
• Disassembly operations do in reverse sequence�
After the protective cover 11 is mounted,
check the latching reliability, the
protective cover 11 must not be displaced
while swinging it. When performing the
mounting operations, take care not to be injured
by knife 29.
Installation / replacement of the cutting accessories
(see gs. 4-6)
Preliminary actions (see g. 4)
Attention: treading on spindle 32 is a left-
hand one, so take this into consideration
when performing the installation
operations.
• Turn over the tool so that the cutting accessory is
directed upwards�
• Align openings on cover 30 and inner ange 31 and
insert Allen key 23 into them to prevent spindle 32
from rotating (see g. 4). Attention: after fullling the
below mentioned installation operations be sure to
remove Allen key 23 to release spindle 32.
Mounting / demounting of the spool with the
cutting line (see g. 5)
• When demounting, unscrew spool 13 by hand and
remove it (see g. 5). After this remove outer ange 33
from spindle 32�
• When mounting, install outer ange 33 on spindle 32
(as shown on g. 5) and manually screw on spool 13�
Mounting / demounting of the cutting disc (see g. 6)
• When demounting, unscrew nut 34, using multi-
purpose wrench 26, and remove it (see g. 6). After
this remove cap 35, outer ange 33 and cutting disc 21
from spindle 32�
• When mounting, install cutting disc 21, outer
ange 33 (as shown in g. 6), cap 35 on spindle 32 and
tighten nut 34 with multi-purpose wrench 26� When
mounting, direction of the arrow on the cutting disc 21
must always coincide with the direction of the arrow on
the protective cover 11�
Attention: when performing the mount-
ing operations, observe the sequence of
installing the parts and do not turn them
over.
Carrying belt (see g. 7-8)
• Put on carrying belt 20 (see g. 7), adjust the length
of the belt in such a way that you feel comfortable and
suspend the tool on the safety catch of carrying belt 20�
The cutting accessory should touch the ground. If this
is not the case, make adjustment.
• Loosen the clamping bolt 36 with the Allen key 23
(see g. 8).
• Move the fastening 7 to the desired position by
sliding it along the tube 8�
• Tighten the clamping bolt 36 with the Allen key 23�
Initial operating of the tool
Mandatory check
Prior to commencing the work, be sure to check the
following:
• correctness of mounting and reliability of xing of all
elements of the tool;
