o(iasoline
is
extremely
flammable and can
be explosive
undel certain
conditioB,
Turn dte ignition switah
OFF. Do
not snoke.
Make surs
the arot b wdl
yentilated
and
free
lrom any source of
flame ot sparkt;
drb includes any
apdiance
wilft a
pilot
light.
oBe
prcpared
for fuel spillage.
lnstallation
Nota
.Connect
the
fuel
hoses
to the
pump
fittings
as shown.
A. Fuel Hose
from Filter
B.
Fuel Hos€ to Carburetors
.Be
sure
to route
the hoses so they will
not be kinked or
stretched.
Fuel Filter
Removal
aRemove
the
fuel
tank.
.Remove
the RH
frame
toD tube
cover.
.Pull
the filter off tl|e hose.
l-wnnruruol
l-
ocasoline
b cxlrsmely
flammable
and
can be sxploEiv€
under
csnsin
conditions. Tum the ignition rwitdr
OFF. Do not 3moke. Make lure the
area is well
ventilated and
frss from
any rcurca
of flame or :perkr;
thb
indudes
any
appliance wi$ a
pilot
light.
oBe
prepared
for fusl
spillsgE.
Installation Notes
alnstall
the
fuel filter
so
that
the arrow on
it
shows the
fuel
flow from the fuel tank to the fuel
pump.
FUEL SYSTEM 2.15
A. Fuel
Hose from Tank C. Arrow
B. Fuel Hos€ to
Pump
.Be
sure
to route the
hoses so they
will not be kinked
or stretched,
lnspection
oVisually
inspect the
fuel filter.
*lf
the
filter is
clear with no signs of
dirt or other
contamination,. it
is OK and
need not
be
replaced.
ilf
tlre filter is dark
or looks dirty,
replace it. Also,
check
the
rest of the
fuel sysGm for
contamination.
Air Cleaner
Element
(Housing)
Remowl
aRemove
the
following
parts.
Seat
FuelTank
Frame Top
Tube Cover
Radiator Cover
oRemove
the
air cleaner
housing mounting bolts.
A. Air Cleaner
Housing B. Bolts
