Epson L800 [105/105] Table 4 3 fatal error list
![Epson L800 [105/105] Confidential](/views2/1131806/page105/bg69.png)
L800/L801 Revision A
Appendix Fatal Error Code 105
Confidential
Note "*": Not occurs except in manufacturing process.
Printhead
system
error
40H
Transistor temperature
error
• Main Board failure
41H
X-Hot detection error
(before printing)
• Printhead failure
• Main Board failure
42H
X-Hot detection error
(before flushing)
43H Head temperature error
Sequence
error
50H
Home position seeking
error
•Paper jam
• Foreign object
• Deformation of the frame
51H CR lock release error
52H CR lock error
53H
Card error
(before initial ink charge)
• Foreign object
56H
Impossible contact error
(at powering off)
---*
Sensor
error
60H
PW sensor error
(Hi check error)
• PW Sensor failure
• Main Board failure
61H
PW sensor error
(Low check error)
62H Tray sensor error
• CDR Tray Sensor failure
• Main Board failure
63H PE sensor error
• PE Sensor failure
• PE Sensor Lever failure
• Main Board failure
Table 4-3. Fatal Error List
Error type
Error
code
Error name Possible cause
Mainte-
nance error
A0H Waste ink overflow
• The maintenance counter has reached a limit.
(Waste Ink Tray or Waste Ink Pad Lower)
Abnormal
operation
88H
Tray insertion error
(during cleaning)
• Foreign object
• CDR Tray Sensor failure
• Main Board failure
89H
Impossible contact error
(during cleaning)
• Paper jam
• Foreign object
• Deformation of the frame
• PF Motor failure
• PF drive mechanism overload (paper jam/
foreign object)
Table 4-3. Fatal Error List
Error type
Error
code
Error name Possible cause
