![Epson L800 [51/105] Confidential](/views2/1131806/page51/bg33.png)
L800/L801 Revision A
Disassembly/Reassembly CR Motor 51
Confidential
When routing the CR Motor Cable and PE Sensor Cable, refer
to Fig.1-88 and follow the steps below.
1. Wrap the CR Motor Cable with the acetate tape A (30 mm)
at the position of 100 mm away from the acetate tape that is
on the CR Motor side.
2. Tie the two cables together with the acetate tape B (20 mm)
at the position 60mm/40mm away from the acetate tape A/
PE Sensor connector.
3. Route the center of the acetate tape A behind the convex
portion of the Main Frame, and secure the tied cables with
the hook (1) at the center of the acetate tape B so that the
CR Motor Cable faces toward you.
4. Wrap the CR Motor Cable and PE Sensor Cable with
acetate tapes (20 mm) at the positions of the hooks (2) (3),
then secure the center of the acetate tapes with Hooks (2)
(3).
Figure 1-88. Routing the Cable
: Hook
PE Sensor
1
0
0
m
m
(
b
e
t
w
e
e
n
b
o
t
h
e
n
d
s
o
f
a
c
e
t
a
t
e
t
a
p
e
s
)
6
0
m
m
(
b
e
t
w
e
e
n
b
o
t
h
e
n
d
s
o
f
a
c
e
t
a
t
e
t
a
p
e
s
)
P
E
S
e
n
s
o
r
C
a
b
l
e
4
0
m
m
(
f
r
o
m
c
o
n
n
e
c
t
o
r
t
o
e
n
d
o
f
a
c
e
t
a
t
e
t
a
p
e
)
2
3
Convex
Portion of
Main
Frame
A
CR Motor
B1
Lubrication is required. See the page given below for the
lubrication information.
Lubrication of Driven Pulley (p.90)
When installing the CR Motor, install it so that the print side
faces upwards.
Figure 1-89. Reinstalling the CR Motor
A D J U S T M E N T
R E Q U I R E D
Whenever the CR Motor is replaced, the required adjustments
must be carried out.
• Refer to "2.1.2 Required Adjustments" (p.74)
