L800/L801 Revision A
Confidential
Disassembly/Reassembly Disassembling/Reassembling Flowchart 21
Porous Pad
Paper Guide
Front
---
---
(p 57)
Waste Ink Tray
2
1
(p 42)
(p 69)
S4
PF Motor
2
---
(p 49)
(p 69)
S17
PF Encoder/
PF Scale
Driven Pulley
Shaft
---
---
Driven Pulley
Holder
---
---
P/S Assy
1
---
(p 34)
(p 69)
S4
Waste Ink Pad
Lower
---
---
Guide Stacker
Right
---
---
---
Label CDR
---
---
---
Guide Stacker
Right Assy
1
---
S6
CDR Guide
Sensor
---
2
---
Guide Stacker
Left
1
---
S6
Stacker Cover
Stacker Assy
Housing Lower
(W/Foot)
---
---
---
P/S Assy
Waste Ink Pad
Cap
Waste Ink Pad
Lower
CR Motor
2
---
S16
Driven Pulley
Assy
---
---
Extension Spring
---
2
---
Housing Lower
Assy
---
---
---
Printer
Mechanism
5
4
(p 35)
(p 69)
S6
Cover Case
1
---
(p 65)
S6
C
4
4
“ 1.5.7 Left & Right Guide
Stackers / CDR Guide Sensor
(p44)”
Driven Pulley
---
---
“ 1.5.12 CR Motor (p50)”
D
Screw type/torque list
Symbol Screw type Torque
C.B.P. 2.6X8 3.5-4.5kgf.cm
C.B.P. 2.6X8 3-5kgf.cm
C.B.P. 3X10 3-5kgf.cm
C.B.P. 3X10 5-7kgf.cm
C.B.P. 3X6 3-5kgf.cm
C.B.P. 3X8 5-7kgf.cm
C.B.P.(P2) 3X8 5-7kgf.cm
C.B.S 3X6 5-7kgf.cm
C.B.S. (P2) 3X8 6-8kgf.cm
C.B.S. (P4) 3X6 7-9kgf.cm
C.B.S. (P4) 3X6 9-11kgf.cm
C.B.S. 3X10 4-6kgf.cm
C.B.S. 3X6 4-6kgf.cm
C.B.S. 3X6 5-7kgf.cm
C.B.S. 3X6 7-9kgf.cm
C.P. 3X4 3-5kgf.cm
C.P. 3X6 3-5kgf.cm
C.P. 3X6 4-6kgf.cm
S1
S2
S3
S4
S5
S6
S7
S8
S9
S10
S11
S12
S13
S14
S15
S16
S17
S18
(p 20) (p 21)
(p 21)
(p 22)
“ 1.5.6 Waste Ink Pad Lower / Waste Ink Pad Cap Lower (p43)”
Waste Ink Pad
Cap Lower
---
---
