L800/L801 Revision A
Adjustment Adjustment Items and Overview 72
Confidential
Table 2-2. Maintenance Items
Maintenance Item
Purpose Method Outline Tool
Head cleaning
This function is used to execute Cleaning efficiently when ink is not
delivered from the Head properly, e.g. dot missing.
The cleaning can be selected from the normal cleaning or the power
cleaning. Whether to reflect the discharged ink amount to the waste ink
pad counter or not can also be selected as an option. The head cleaning is
performed automatically. After the cleaning, print a nozzle ch
eck pattern
to check if all nozzles are firing ink properly.
• Adjustment Program
Maintenance counter
The printer causes a maintenance error when the maintenance counter
(for the Waste Ink Tray, Waste Ink Pad Lower) reaches its maximum.
Use this to reset the counter after replacing the Waste Ink Pad and Waste
Ink Pad Lower, and use this to reset the ink tube counter when replacing
the Ink Supply Tube. If you find the counter is close to the maximum
during servicing, carry out the pad replacement and the counter reset to
avoid the printer returned from the user due to the maintenance error.
Select the replaced parts, and reset the corresponding counters.
• Adjustment Program
Ink charge
This function is used to charge ink to the components composing the ink
path such as Printhead after replacing them.
The ink charge can be selected from the charge to Printhead only or the
charge through Ink Tube, Adapter to Printhead. Whether to reflect the
discharged ink amount to the waste ink pad counter or not can also be
selected as an option.
Select the range to charge ink and options, and then press the execute
button to execute the ink charge to the selected range automatically.
After ink charge, print a nozzle check pattern to check if all nozzles are
firing ink properly.
• Adjustment Program
Small ink counter reset
When an ink out error occurs even though some ink is still in the Ink
Supply Tank Assy (in the case when the ink counter in the printer and the
actual ink remaining amount do not match), this function can decrease
the ink counter (resetting the counter partially) to adjust the counter with
the actual ink remaining amount.
If the execute button is pressed, the ink counter value is automatically
set. But if no ink out error is occurring, the message which says the
function cannot be executed appears and no reset will be made.
• Adjustment Program
Table 2-3. Additional Functions
Additional Functions
Purpose Method Outline Tool
Final check pattern
print
A4 size Use this to check if the all adjustments have been
properly made.
The all adjustment patterns are printed automatically.
• Adjustment Program
US Letter size
EEPROM dump Use this to readout the EEPROM data for analysis. The all EEPROM data is automatically readout and stored as a file.
• Adjustment Program
