D-Link DCS-3220G [11/143] Installation wizard continued

The InstallShield will install in

the following folder. To install

into a different folder, click

Browse and select another

folder.

Click Next.

Select the Program folder

that Setup will add program

icons to. You may type a new

folder name, or select one

from the existing folders list.

Click Next.

Please wait while the

Installation Wizard is

installed.

Installation Wizard (continued)
