D-Link DCS-3220G [35/143] Using the dcs 3220g with an internet browser continued

Home Page Screen

The image from the DCS-3220G should be visible from the Home page on your

computer monitor.

Using the DCS-3220G with an Internet

browser (continued)

Click on the Connection Type button to change settings related to the

connection.

There are two

buttons on the left

side of the Home

page:

Connection Type

and

Configuration.

Click Connection Type
