54
Configuration > Tools > System
Manual - Adjust the date and time according to what is
entered by the administrator. Notice the format in
the related field while typing.
Automatic - Synchronize with the NTP server over the Internet
whenever the DCS-3220G starts up. It will fail if
the assigned timeserver cannot be reached.
NTP server - Assign the IP address or domain name of the
timeserver. Leaving the text box blank will let the
DCS-3220G connect to default time servers.
Time zone - Used to adjust the hour of time servers for local
settings.
Keep current date and
time -
Using the DCS-3220G with an Internet
browser (continued)
Click to save the current date and time of
DCS-3220G. An internal real-time clock maintains
the date and time even when the power is off.
Sync with computer time-
Click Apply to make
changes effective
Synchronize the date and time of DCS-3220G
with the local computer. The date and time of the
PC is displayed and updated in the DCS-3220G.
